Manufacturer | ASV |
Model | MD 70 |
Type | Compact track loader |
Lift Design | Radial |
Years Made | Unknown |
Asv Md70 Specs
The following tables include a listing of the Asv Md70 specs. When review the table of Asv Md70, it is important to take into consideration the production year. The user's manuals provided by the manufacturer were consulted in order to ascertain the appropriate values for the Asv Md70's weight, lifting capability, and horsepower, among other technical specifications. Before you make a purchase, it is must that you verify the product's technical specs with the vendor. In order to assist you in making an informed buying decision, we will provide an Asv Md70 review as soon as feasible.
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 70 HP | 52.2 kW |
Lifting Capacity (35% Tipping) | 1500 lbs | 680.4 kg |
Lifting Capacity (50% Tipping) | 2200 lbs | 997.9 kg |
Operating Weight | 6800 lbs | 3084 kg |
Tipping Load | ||
Lift Breakout Force | 4400 lbs | 1996 kg |
Tilt Breakout Force | ||
Max. Travel Speed | 8.0 mph | 12.9 km |
Ground pressure | 2.6 psi | 17.9 kPa |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 18 GPM | 68 LPM |
Relief Pressure | 3000 psi | 210 Bar |
Optional Flow | 25 GPM | 95 LPM |
Hydraulic Capacity | 27.0 gal | 102.2 L |
The Asv Md70 weighs 6,800 pounds.
The ASV 70 is powered by an Isuzu 4JB1 engine.
The oil capacity of the Asv MD70 is 1.5 gallons.
The ASV MD 70 has a 70-horsepower rating.
Asv Md-70 lifts 2,200 lbs.
Engine Specs
Manufacturer | Isuzu |
Model | 4JB1 |
Type | Diesel |
Cylinders | 4 |
Rated Speed | 3000 RPM |
Torque Power | 1200 RPM |
Combustion | Direct injection |
Emissions | |
Compression Ratio | 18.2:1 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 70.0 HP | 52.2 kW |
Displacement | 169 cu in. | 2771 cc |
Bore | 3.7 in. | 9.3 cm |
Stroke | 4.0 in. | 10.2 cm |
Peak Torque | 291 ft-lb | 394.5 N∙m |
Coolant Capacity | 3.0 gal | 11.0 L |
Engine Oil Capacity | 1.5 gal | 5.5 L |
Fuel Tank Capacity | 13 gal | 49.2 L |
Dimensions
US | Metric | |
---|---|---|
Height | 78.0 in. | 198.1 cm |
Bucket Hinge Pin | 110.0 in. | 279.4 cm |
Width | 64.0 in. | 162.6 cm |
Length | 113.0 in. | 287.0 cm |
Ground Clearance | 14.0 in. | 35.6 cm |
Undercarriage
US | Metric | |
---|---|---|
Track Width | 18.0 in. | 45.7 cm |
Track Length | 220.0 in. | 558.8 cm |
Track Weight | 265.0 lbs | 120.2 kg |
Ground Contact Area | 2,826 in² | 18,232 cm² |
There may be some minor issues, but I think the MD70 is a good installer overall. In fact, the RTSS undercarriage on the latest machines was modeled after the MD70, which proved successful for a number of contractors. The Asv MD70 was thought to be pretty well made by most people.ASV Md70 Review
