Manufacturer | ASV |
Model | RC 50 |
Type | Compact track loader |
Lift Design | Radial |
Years Made | Unknown |
Asv Rc50 Specs
Detailed information on the Asv Rc50 specs may be found in the tables below. We advise keeping the Asv Rc50's model year in mind when perusing its technical specs. The Asv Rc50's dimensions, weight, horsepower, and lifting capacity were take advantage of from the owner's manuals. Before you buy an Asv Rc50, it's important to double-check the specifications with the vendor. The AAsv Rc50 review that you've been waiting for will be available on our site shortly.
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 50.0 HP | 37.3 kW |
Lifting Capacity (35% Tipping) | 1330 lbs | 603.3 kg |
Lifting Capacity (50% Tipping) | 1900 lbs | 861.8 kg |
Operating Weight | 6200 lbs | 2812.3 kg |
Tipping Load | 3800 lbs | 1723.7 kg |
Lift Breakout Force | ||
Tilt Breakout Force | ||
Max. Travel Speed | 6.0 mph | 9.7 km |
Ground pressure | 2.5 psi | 17.5 kPa |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 17.4 GPM | 65.9 LPM |
Relief Pressure | 3000 psi | 210 Bar |
Optional Flow | N/A | |
Hydraulic Capacity | 8.0 gal | 30.3 L |
The Asv Rc50 is 6,200 pounds in weight.
The Asv Rc50 has a lifting capacity of up to 1,900 pounds.
The ASV RC50 is powered by 50 horsepower.
The ASV RC50 has a Perkins 404C-22 engine.
The oil capacity of the ASV RC50 is 2.8 gallons.
Engine Specs
Manufacturer | Perkins |
Model | 404C-22 |
Type | Diesel |
Cylinders | 3 |
Rated Speed | 2800 RPM |
Torque Power | 2400 RPM |
Combustion | Indirect injection |
Emissions | |
Compression Ratio | 23.3:1 |
Firing Order | 1-2-3 |
US | Metric | |
---|---|---|
Gross Power | 50.0 HP | 37.3 kW |
Displacement | 135.2 cu in. | 2216 cc |
Bore | 3.3 in. | 8.4 cm |
Stroke | 3.9 in. | 10.0 cm |
Peak Torque | 105 ft-lb | 143 N∙m |
Coolant Capacity | 2.0 gal | 7.5 L |
Engine Oil Capacity | 2.8 gal | 10.6 L |
Fuel Tank Capacity | 15.0 gal | 56.8 L |
Dimensions
US | Metric | |
---|---|---|
Height | 77.0 in. | 195.6 cm |
Bucket Hinge Pin | 115.0 in. | 292.1 cm |
Width | 60.0 in. | 152.4 cm |
Lenght | 128.0 in. | 325.1 cm |
Ground Clearance | 12.0 in. | 30.5 cm |
Undercarriage
US | Metric | |
---|---|---|
Track Width | 15.0 in. | 38.1 cm |
Track Length | 59.0 in. | 150.0 cm |
Track Weight | ||
Ground Contact Area | 1,770 in² | 11,419 cm² |
The ASV RC50 is a well-known loader that is utilized for various agricultural tasks. Users are satisfied with both its power and its size.ASV RC50
