| Manufacturer | ASV |
| Model | RC 85 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | Unknown |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 86.0 HP | 64.0kW |
| Lifting Capacity (35% Tipping) | 2380 lbs | 1079.5 kg |
| Lifting Capacity (50% Tipping) | 3400 lbs | 1542.2 kg |
| Operating Weight | 9710 lbs | 4404.4 kg |
| Tipping Load | 9700 lbs | 4399.8 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 6.0 mph | 9.7 km |
| Ground pressure | 3.3 psi | 22.7 kPa |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 20 GPM | 76 LPM |
| Relief Pressure | 3300 psi | 228 Bar |
| Optional Flow | 38 GPM | 144 LPM |
| Hydraulic Capacity | 20.0 gal | 76.0 L |
Engine Specs
| Manufacturer | Perkins |
| Model | 1104C-44 |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2400 RPM |
| Torque Power | 1200 RPM |
| Combustion | Indirect injection |
| Emissions | Stage II/Tier 2 |
| Compression Ratio | 19.3:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 86.0 HP | 64.0kW |
| Displacement | 269 cu in. | 4408 cc |
| Bore | 4.1 in. | 10.5 cm |
| Stroke | 5.0 in. | 12.7 cm |
| Peak Torque | 222 ft-lb | 301 N∙m |
| Coolant Capacity | 3.1 gal | 12.0 L |
| Engine Oil Capacity | 2.1 gal | 8.0 L |
| Fuel Tank Capacity | 26.0 gal | 98.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 80.0 in. | 202.3 cm |
| Bucket Hinge Pin | 125.0 in. | 317.5 cm |
| Width | 69.0 in. | 175.3 cm |
| Length | 148.0 in. | 376.0 cm |
| Ground Clearance | 14.0 in. | 35.6 cm |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 18.0 in. | 45.7 cm |
| Track Length | 72.5 in. | 184.2 cm |
| Track Weight | ||
| Ground Contact Area | 2,610 in² | 16,838 cm² |
