Manufacturer | ASV |
Model | RT60 |
Type | Compact track loader |
Lift Design | Radial |
Years Made | 2017-2022 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 60.0 HP | 44.7 kW |
Lifting Capacity (35% Tipping) | 1900 lbs | 861.8 kg |
Lifting Capacity (50% Tipping) | 2715 lbs | 1231.5 kg |
Operating Weight | 6930 lbs | 3143.4 kg |
Tipping Load | 5430 lbs | 2463.0 kg |
Lift Breakout Force | ||
Tilt Breakout Force | ||
Max. Travel Speed | 6.0 mph | 9.7 km |
Optional High Speed | 11.0 mph | 17.7 km |
Ground Pressure | 3.9 psi | 26.9 kPa |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 17.4 GPM | 65.9 LPM |
Relief Pressure | 3000 psi | 206.8 bar |
Optional Flow | N/A | |
Hydraulic Capacity | 8.0 gal | 30.3 L |
Engine Specs
Manufacturer | Perkins |
Model | 404D-22T |
Type | Diesel |
Cylinders | 4 |
Rated Speed | 3000 RPM |
Torque Power | 1800 RPM |
Combustion | Indirect injection |
Emissions | Tier 4 Final |
Compression Ratio | 23.3:1 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 60.0 HP | 44.7 kW |
Displacement | 135 cu in. | 2212 cc |
Bore | 3.3 in. | 8.4 cm |
Stroke | 3.9 in. | 10.0 cm |
Peak Torque | 140 ft-lb | 189.8 N∙m |
Coolant Capacity | 2.0 gal | 7.5 L |
Engine Oil Capacity | 2.8 gal | 10.6 L |
Fuel Tank Capacity | 13.7 gal | 51.9 L |
Dimensions
US | Metric | |
---|---|---|
Height | 77.0 in. | 195.6 cm |
Bucket Hinge Pin | 115.5 in. | 293.4 cm |
Width | 66.0 in. | 167.6 cm |
Length | 128.0 in. | 325.1 cm |
Dump Height | 91.0 in. | 231.1 cm |
Dump Reach | 25.0 in. | 63.5 cm |
Ground Clearance | 14.0 in. | 36.5 cm |
Dump Angle | 32° |
Rollback Angle | 20° |
Departure Angle | 42° |
Undercarriage
US | Metric | |
---|---|---|
Track Width | 15.0 in. | 38.1 cm |
Track Length | 59.0 in. | 149.9 cm |
Track Weight | ||
Ground Contact Area | 1,770 in² | 11,419 cm² |
