Bobcat 530

Bobcat 530 specs
ManufacturerBobcat
Model530
TypeSkid steer loader
Lift DesignVertical
Years Made1977-1982

Bobcat 530 Specs

Details about the Bobcat 530 specs are listed below. When looking at the technical specs of the Bobcat 530, we suggest keeping the model year in mind. The manufacturer's manuals were used to list the Bobcat 530's weight, horsepower, lifting capacity, and other specifications. Before you buy the Bobcat 530, check with the seller about the technical specs. We will soon add a review of the Bobcat 530 to help you with your purchase.

Operating Specifications

USMetric
Horsepower19.0 HP14.2 kW
Lifting Capacity (35% Tipping)550 lbs249.5 kg
Lifting Capacity (50% Tipping)800 lbs362.9 kg
Operating Weight3100 lbs1406.1 kg
Tipping Load3750 lbs1701.0 kg
Lift Breakout Force
Tilt Breakout Force
Max. Travel Speed5.5 mph8.9 km

Cycle Time

Raise Lift Arms4.0 sec.
Lower Lift Arms3.0 sec.
Bucket Rollback2.0 sec.
Bucket Dump2.5 sec.

Hydraulic System

USMetric
Pump Flow8.3 GPM32.1 LPM
Relief Pressure1500 psi103.4 Bar
Optional FlowN/A
Hydraulic Capacity5.5 gal21.0 L
How much can a Bobcat 530 lift?

Bobcat 530 lifts 800 lbs.

What engine is in a Bobcat 530?

The Bobcat 530 is powered by a Kohler K582 engine.

How much does a Bobcat 530 weigh?

The Bobcat 530 weighs 3,100 pounds.

What is the Bobcat 530’s oil capacity?

The Bobcat 530 oil capacity is 1 gallon.

What horsepower is a Bobcat 530?

The Bobcat 530 has a horsepower rating of 19 HP.

Engine Specs

ManufacturerKohler
ModelK582
TypeGasoline
Cylinders2
EmissionsN/A
Rated Speed2500 RPM
Torque Power2200 RPM
Combustion
Compression Ratio
Firing Order
USMetric
Gross Power21.5 HP16.0 kW
Net Power19.0 HP14.2 kW
Displacement57.7 cu. in.946 cc
Bore3.5 in.8.8 cm
Stroke3.0 in.7.6 cm
Peak Torque40.8 ft-lb55.3 N∙m
Coolant Capacity
Engine Oil Capacity1.0 gal3.8 L
Fuel Tank Capacity10.0 gal37.9 L

Dimensions

USMetric
Height72.5 in.184.2 cm
Bucket Hinge Pin102.5 in.260.3 cm
Width47.2 in.119.9 cm
Length104.0 in.264.2 cm
Dump Height85.0 in.215.9 cm
Dump Reach32.0 in.81.3 cm
Ground Clearance7.2 in.18.3 cm
Dump Angle42°
Rollback Angle24°
Departure Angle27°

Tire Size

Front5.70×15
Rear5.70×15

Bobcat 530 Review

Reliability
Specifications
Power
Price

The Bobcat 530 is a loader that can see your job for light work and can help you complete it. If you work on a flat floor or in confined spaces, it might be a smart investment to make this purchase. If you need a more powerful alternative, look at the Bobcat 743.

User Rating: Be the first one !
