Bobcat 751

Bobcat 751
ManufacturerBobcat
Model751C
TypeSkid steer loader
Lift DesignVertical
Years Made1992-2000

Bobcat 751 Specs

The following tables list the Bobcat 751 specs. When looking at the Bobcat 751 table, keep in mind the year. User manuals were used to determine the Bobcat 751's weight, lifting capacity, horsepower, and other technical requirements. Before buying, check the product's technical specs with the seller. We'll publish an Bobcat 751 review as soon as possible to help you buy.

Operating Specifications

USMetric
Horsepower37.5 HP12.3 kW
Lifting Capacity (35% Tipping)750 lbs340.2 kg
Lifting Capacity (50% Tipping)1300 lbs589.7 kg
Operating Weight5000 lbs2267.9 kg
Tipping Load2500 lbs1134.0 kg
Lift Breakout Force2360 lbs1070.5 kg
Tilt Breakout Force2380 lbs1079.5 kg
Max. Travel Speed6.1 mph9.8 km

Cycle Time

Raise Lift Arms3.4 sec.
Lower Lift Arms2.1 sec.
Bucket Rollback2.0 sec.
Bucket Dump2.4 sec.

Hydraulic System

USMetric
Pump Flow12.9 GPM49.0 LPM
Relief Pressure2550 psi175.8 Bar
Optional FlowN/A
Hydraulic Capacity5.8 gal22 L
What years did they make the Bobcat 751?

Bobcat 751 was produced from 1992 to 2000.

How much can a Bobcat 751 lift?

Bobcat 751 lifts 1,300 lbs.

What weight is a Bobcat 751?

Bobcat 751 is 5,000 pounds in weight.

How many HP is a Bobcat 751?

The Bobcat 751 has a horsepower rating of 37.5 HP.

What engine is in a Bobcat 751?

The engine that powers the Bobcat 751 is a Kubota V1903E model.

What is the Bobcat 751’s oil capacity?

The Bobcat 751 oil capacity is 1.9 gallons.

Engine Specs

ManufacturerKubota
ModelV1903E
TypeDiesel
Cylinders4
EmissionsN/A
Rated Speed2700 RPM
Torque Power1800 RPM
CombustionSpherical Type (E TVCS)
Compression Ratio23:1
Firing Order1-3-4-2
USMetric
Gross Power37.5 HP28.0 kW
Net Power35.5 HP26.5 kW
Displacement113 cu. in.1857 cc
Bore3.2 in.8.0 cm
Stroke3.6 in.9.2 cm
Peak Torque86.3 ft-lb117.0 N∙m
Coolant Capacity3.2 gal12.3 L
Engine Oil Capacity1.9 gal7.1 L
Fuel Tank Capacity14.0 gal53.0 L

Dimensions

USMetric
Height76.0 in.193.0 cm
Bucket Hinge Pin109.1 in.277.1 cm
Width54.0 in.137.2 cm
Length122.2 in.310.5 cm
Dump Height84.6 in.214.8 cm
Dump Reach19.1 in.48.5 cm
Ground Clearance7.1 in.18.0 cm
Dump Angle40°
Rollback Angle25°
Departure Angle26°

Tire Size

Front10-16.5
Rear10-16.5

Bobcat 751C Review

Reliability
Specifications
Performance
Price

The Bobcat 751c was produced with the Peugeot engine to reduce cost. That's why a lot of users were undecided about this installer. Although the technical specifications look good, I have come across users who have problems in cold weather. Those equipped with another option, the Kubota engine, are considered better.

User Rating: Be the first one !
