| Manufacturer | Bobcat |
| Model | 873 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 1995-1999 |
| Variants | Bobcat 873G Bobcat 873HG Bobcat 873G |
Bobcat 873 Specs
A information of the Bobcat 873 specs can be found in the tables that follow. When looking at the table for the Bobcat 873, it is essential to take into account the manufacturing year. In order to determine the true information for the Bobcat 873's weight, lifting capabilities, and horsepower, among other technical requirements, the user's manuals that were supplied by the manufacturer were read. It is essential that you consult the seller in order to confirm the product's technical specifications before making a purchase. We will published an Bobcat 873 review as soon as it is possible, with the goal of assisting you in making an true purchasing choice.
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 73.5 HP | 54.8 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 2300 lbs | 1044 kg |
| Operating Weight | 6850 lbs | 3107.1 kg |
| Tipping Load | 4600 lbs | 2086.5 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 8.4 mph | 13.5 km |
Cycle Time
| Raise Lift Arms | 5.0 sec. |
| Lower Lift Arms | 4.6 sec. |
| Bucket Rollback | 1.8 sec. |
| Bucket Dump | 2.3 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.0 GPM | 68.1 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 13.0 gal | 49.2 L |
Bobcat 873 lifts 2,300 lbs.
The Bobcat 873 was produced from 1995 to 1999.
The Bobcat 873 has a weight of 6,850 pounds.
The Bobcat 873 does not have high flow.
The Bobcat 873 is powered by a Deutz BF4M 1011 engine.
The cabin comfort of the Bobcat G series is its most notable feature. Bobcat loaders have gotten more comfortable as a result of this series.
Engine Specs
| Manufacturer | Deutz |
| Model | BF4M 1011 |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2600 RPM |
| Torque Power | 1800 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.5:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 73.5 HP | 54.8 kW |
| Displacement | 134 cu in. | 2195 cc |
| Bore | 3.6 in. | 9.1 cm |
| Stroke | 4.1 in. | 10.5 cm |
| Peak Torque | 164 ft-lb | 222.4 N∙m |
| Coolant Capacity | 4.3 gal | 16.1 L |
| Engine Oil Capacity | 2.5 gal | 9.5 L |
| Fuel Tank Capacity | 25.0 gal | 94.6 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.0 in. | 198.1 cm |
| Bucket Hinge Pin | 124.3 in. | 315.7 cm |
| Width | 74.0 in. | 188.0 cm |
| Lenght | 140.3 in. | 356.4 cm |
| Dump Height | 97.3 in. | 247.1 cm |
| Dump Reach | 33.2 in. | 84.3 cm |
| Ground Clearance | 8.5 in. | 21.6 cm |
| Dump Angle | 40° |
| Rollback Angle | 30° |
| Departure Angle | 28° |
Tire Size
| Front | 12×16.5 |
| Rear | 12×16.5 |
Skid steer loaders like the Bobcat 873 are both practical and powerful. It is one of the models you should unquestionably take into consideration if you are unable to purchase a new mini loader.Bobcat 873 Review
