| Manufacturer | Bobcat |
| Model | 873 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 1995-1999 |
| Variants | Bobcat 873G Bobcat 873HG Bobcat 873G |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 73.5 HP | 54.8 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 2300 lbs | 1044 kg |
| Operating Weight | 6850 lbs | 3107.1 kg |
| Tipping Load | 4600 lbs | 2086.5 kg |
| Lift Breakout Force | ||
| Tilt Breakout Force | ||
| Max. Travel Speed | 8.4 mph | 13.5 km |
Cycle Time
| Raise Lift Arms | 5.0 sec. |
| Lower Lift Arms | 4.6 sec. |
| Bucket Rollback | 1.8 sec. |
| Bucket Dump | 2.3 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.0 GPM | 68.1 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 13.0 gal | 49.2 L |
Engine Specs
| Manufacturer | Deutz |
| Model | BF4M 1011 |
| Type | Diesel |
| Cylinders | 4 |
| Rated Speed | 2600 RPM |
| Torque Power | 1800 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.5:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 73.5 HP | 54.8 kW |
| Displacement | 134 cu in. | 2195 cc |
| Bore | 3.6 in. | 9.1 cm |
| Stroke | 4.1 in. | 10.5 cm |
| Peak Torque | 164 ft-lb | 222.4 N∙m |
| Coolant Capacity | 4.3 gal | 16.1 L |
| Engine Oil Capacity | 2.5 gal | 9.5 L |
| Fuel Tank Capacity | 25.0 gal | 94.6 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.0 in. | 198.1 cm |
| Bucket Hinge Pin | 124.3 in. | 315.7 cm |
| Width | 74.0 in. | 188.0 cm |
| Lenght | 140.3 in. | 356.4 cm |
| Dump Height | 97.3 in. | 247.1 cm |
| Dump Reach | 33.2 in. | 84.3 cm |
| Ground Clearance | 8.5 in. | 21.6 cm |
| Dump Angle | 40° |
| Rollback Angle | 30° |
| Departure Angle | 28° |
Tire Size
| Front | 12×16.5 |
| Rear | 12×16.5 |
