| Manufacturer | Bobcat |
| Model | A300 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2002-2009 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 81.0 HP | 60.3 kW |
| Lifting Capacity (35% Tipping) | 2100 lbs | 952.5 kg |
| Lifting Capacity (50% Tipping) | 3000 lbs | 1360.8 kg |
| Operating Weight | 8709 lbs | 3950.3 kg |
| Tipping Load | 6111 lbs | 2771.9 kg |
| Lift Breakout Force | 6601 lbs | 2994.0 kg |
| Tilt Breakout Force | 7166 lbs | 3250.4 kg |
| Max. Travel Speed | 6.9 mph | 11.1 km |
| Optional High Speed | 12 mph | 19.3 km |
Cycle Time
| Raise Lift Arms | 4.4 sec. |
| Lower Lift Arms | 3.2 sec. |
| Bucket Rollback | 1.9 sec. |
| Bucket Dump | 2.5 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 20.7 GPM | 78.4 LPM |
| Relief Pressure | 3300 psi | 227.5 Bar |
| Optional Flow | 36.7 GPM | 138.9 LPM |
| Hydraulic Capacity | 13.0 gal | 49.2 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V3800-DI-TE3 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2400 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Compression Ratio | 19.0 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 81.0 HP | 60.3 kW |
| Net Power | 78.0 HP | 58.2 kW |
| Displacement | 230 cu in. | 3769 cc |
| Bore | 3.9 in. | 10.0 cm |
| Stroke | 4.7 in. | 12.0 cm |
| Peak Torque | 218 ft-lb | 295.0 N∙m |
| Coolant Capacity | 4.3 gal | 16.3 L |
| Engine Oil Capacity | 3.5 gal | 13.3 L |
| Fuel Tank Capacity | 23.0 gal | 87.1 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 80.9 in. | 205.5 cm |
| Bucket Hinge Pin | 128.8 in. | 327.2 cm |
| Width | 74.2 in. | 188.5 cm |
| Length | 142.9 in. | 363.0 cm |
| Dump Height | 99.1 in. | 251.7 cm |
| Dump Reach | 33.8 in. | 85.9 cm |
| Ground Clearance | 8.5 in. | 21.6 cm |
| Dump Angle | 41° |
| Rollback Angle | 32° |
| Departure Angle | 25° |
Tire Size
| Front | 12-16.5 |
| Rear | 12-16.5 |
