Bobcat S160

Bobcat s160 specs
ManufacturerBobcat
ModelS160
TypeSkid steer loader
Lift DesignRadial
Years Made2003-2013
The 2005 model bobcat s160 has the following specs. The specifications of the s160 bobcat differ depending on the year it was built.

Bobcat S160 Specs

The tables below show basic of the technical details about the Bobcat S160 specs. When looking at the table for the Bobcat S160, you must take into account the year it was made. The manufacturer's user's manuals were take of advantage to get accurate information about the Bobcat S160's weight, lifting capacity, horsepower, and other technical requirements. Before making a purchase, you must talk to the seller to confirm the product's technical specifications. We will write an Bobcat S160 review as soon as we can, with the goal of helping you make a good buying decision.

Operating Specifications

USMetric
Horsepower58.0 HP43.3 kW
Lifting Capacity (35% Tipping)1100 lbs499.0 kg
Lifting Capacity (50% Tipping)1600 lbs725.7 kg
Operating Weight5752 lbs2609.1 kg
Tipping Load3200 lbs1451.5 kg
Lift Breakout Force4400 lbs1995.8 kg
Tilt Breakout Force3630 lbs1646.5 kg
Max. Travel Speed7.3 mph11.7 km
Optional High Speed11.1 mph17.9 km

Cycle Time

Raise Lift Arms3.7 sec.
Lower Lift Arms2.1 sec.
Bucket Rollback1.9 sec.
Bucket Dump2.4 sec.

Hydraulic System

USMetric
Pump Flow16.9 GPM63.0 LPM
Relief Pressure3300 psi227.5 Bar
Optional Flow26.4 GPM99.9 LPM
Hydraulic Capacity8.5 gal32.2 L
How much does a Bobcat S160 weight?

Bobcat S160 is 5,752 pounds in weight.

How much can the S160 Bobcat lift?

Bobcat S160 lifts 1,600 lbs.

How many horsepower is a Bobcat S160?

Bobcat S160 has 58 HP.

What is the engine in the Bobcat S160?

The Bobcat S160 has an engine made by Kubota called the V2003M-DI-T.

What is the Bobcat S160’s oil capacity?

The oil capacity of the Bobcat S160 is 1.9 gallons.

What years did Bobcat make the S160?

The Bobcat S160 was produced from 2003 to 2013.

Engine Specs

ManufacturerKubota
ModelV2003M-DI-T
TypeDiesel
Cylinders4
EmissionsTier 4
Rated Speed2800 RPM
Torque Power1700 RPM
CombustionSpherical Type (E-TVCS)
Compression Ratio23.0
Firing Order1-3-4-2
USMetric
Gross Power58.0 HP43.3 kW
Net Power56.0 HP41.8 kW
Displacement134 cu in.2197 cc
Bore3.3 in.8.3 cm
Stroke3.6 in.9.2 cm
Peak Torque103.5 ft-lb140.3 N∙m
Coolant Capacity3.0 gal11.4 L
Engine Oil Capacity1.9 gal7.1 L
Fuel Tank Capacity23.0 gal87.1 L

Dimensions

USMetric
Height76.3 in.193.8 cm
Bucket Hinge Pin114.5 in.290.8 cm
Width66.0 in.167.6 cm
Length130.3 in.330.9 cm
Dump Height86.5 in.219.7 cm
Dump Reach18.1 in.46.1 cm
Ground Clearance7.5 in.19.1 cm
Dump Angle44°
Rollback Angle25°
Departure Angle23°

Tire Size

Front10-16.5
Rear10-16.5

Bobcat S160 Review

Reliability
Specifications
Price

With the exception of routine maintenance, the Bobcat S160 will not cost you any money. Strong lifting arms, double bucket tilt cylinders, and a turbo Kubota diesel are the main features of the S160. This series, which is the Bobcat 763's continuation, is widely used.
