Manufacturer | Bobcat |
Model | S330 |
Type | Skid steer loader |
Lift Design | Vertical |
Years Made | 2006-2010 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 85.0 HP | 63.4 kW |
Lifting Capacity (35% Tipping) | 2500 lbs | 1134.0 kg |
Lifting Capacity (50% Tipping) | 3300 lbs | 1496.9 kg |
Operating Weight | 9185 lbs | 4166.2 kg |
Tipping Load | 6720 lbs | 3048.1 kg |
Lift Breakout Force | 5550 lbs | 2517.4 kg |
Tilt Breakout Force | 5800 lbs | 2630.8 kg |
Max. Travel Speed | 6.9 mph | 11.1 km |
Optional High Speed | 12 mph | 19.3 km |
Cycle Time
Raise Lift Arms | 4.4 sec. |
Lower Lift Arms | 3.2 sec. |
Bucket Rollback | 2.1 sec. |
Bucket Dump | 2.7 sec. |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 20.7 GPM | 78.4 LPM |
Relief Pressure | 3300 psi | 227.5 Bar |
Optional Flow | 36.7 GPM | 138.9 LPM |
Hydraulic Capacity | 13.0 gal | 49.2 L |
Engine Specs
Manufacturer | Kubota |
Model | V3800-DI-T |
Type | Diesel |
Cylinders | 4 |
Emissions | Tier 3 |
Rated Speed | 2575 RPM |
Torque Power | 1600 RPM |
Combustion | Direct injection |
Compression Ratio | 19.0 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 85.0 HP | 63.4 kW |
Net Power | 82.5 HP | 61.5 kW |
Displacement | 230 cu in. | 3769 cc |
Bore | 3.9 in. | 10.0 cm |
Stroke | 4.7 in. | 12.0 cm |
Peak Torque | 230 ft-lb | 311.8 N∙m |
Coolant Capacity | 4.3 gal | 16.3 L |
Engine Oil Capacity | 3.5 gal | 13.3 L |
Fuel Tank Capacity | 23.0 gal | 87.1 L |
Dimensions
US | Metric | |
---|---|---|
Height | 82.2 in. | 208.8 cm |
Bucket Hinge Pin | 130.1 in. | 330.5 cm |
Width | 73.3 in. | 186.2 cm |
Length | 143.4 in. | 364.2 cm |
Dump Height | 102.5 in. | 260.4 cm |
Dump Reach | 31.2 in. | 79.2 cm |
Ground Clearance | 8.7 in. | 22.1 cm |
Dump Angle | 41° |
Rollback Angle | 31° |
Departure Angle | 26° |
Tire Size
Front | 12-16.5 |
Rear | 12-16.5 |
