Bobcat S630

bobcat s630 specs
ManufacturerBobcat
ModelS630
TypeSkid steer loader
Lift DesignRadial
Years Made2009-2016
The specifications for the Bobcat s630 from 2009 to 2016 models (M series) are listed below.

Bobcat S630 Specs

Detailed information about the Bobcat S630 specs are provided below. We recommend keeping the model year in mind when reviewing Bobcat S630 specs. The specifications of the Bobcat S630, including its weight, horsepower, lifting capacity, and other aspects, were published with the help of the manufacturer's manuals. Verify the Bobcat S630's specs with the seller. Soon, we'll have an ASV Hd4500 review to aid your purchase.

Operating Specifications

USMetric
Horsepower74.3 HP55.4 kW
Lifting Capacity (35% Tipping)1625 lbs737.1 kg
Lifting Capacity (50% Tipping)2180 lbs952.5 kg
Operating Weight7700 lbs3492.7 kg
Tipping Load4360 lbs1977.7 kg
Lift Breakout Force4000 lbs1814.4 kg
Tilt Breakout Force4350 lbs1973.1 kg
Max. Travel Speed7.1mph11.4 km
Optional High Speed12.3 mph19.8 km

Cycle Time

Raise Lift Arms3.4 sec.
Lower Lift Arms3.0 sec.
Bucket Rollback1.7 sec.
Bucket Dump2.3 sec.

Hydraulic System

USMetric
Pump Flow23.0 GPM87.1 LPM
Relief Pressure3550 psi244.8 Bar
Optional Flow30.5 GPM115.5 LPM
Hydraulic Capacity11.0 gal41,6 L
How much can an S630 Bobcat lift?

Bobcat S630 lifts 2,200 lbs.

How much does a Bobcat S630 weight?

Bobcat S630 is 7,700 pounds in weight.

How many horsepower is a Bobcat S630?

The Bobcat S630 has 74 horsepower.

What engine is in a Bobcat S630?

The Bobcat S630’s engine is made by Kubota and has the model number V3307-DI-TE3.

What is the Bobcat S630’s oil capacity?

The oil capacity of the Bobcat S630 is 3 gallons.

Engine Specs

ManufacturerKubota
ModelV3307-DI-TE3
TypeDiesel
Cylinders4
EmissionsTier 4
Rated Speed2400 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio22.6
Firing Order1-3-4-2
USMetric
Gross Power74.3 HP55.4 kW
Net Power70.3 HP52.4 kW
Displacement202.5 cu in.3318 cc
Bore3.7 in.9.4 cm
Stroke4.7 in.12.0 cm
Peak Torque195 ft-lb264.4 N∙m
Coolant Capacity3.1 gal11.7 L
Engine Oil Capacity3.0 gal11.4 L
Fuel Tank Capacity27.2 gal103.1 L

Dimensions

USMetric
Height81.3 in.206.5 cm
Bucket Hinge Pin121.0 in.307.3 cm
Width72.1 in.183.2 cm
Lenght136.8 in.347.4 cm
Dump Height93.2 in.236.7 cm
Dump Reach21.4 in.54.4 cm
Ground Clearance8.1 in.20.7 cm
Dump Angle42°
Rollback Angle31°
Departure Angle25°

Tire Size

Front12-16.5
Rear12-16.5

Bobcat S630 Review

Reliability
Specifications
Price

It also provides simplified serviceability, and maintenance and is extremely durable and powerful. The S630 offers enhanced visibility, improved uptime protection, and comfort for the operator.
