Manufacturer | Bobcat |
Model | S64 |
Type | Skid steer loader |
Lift Design | Vertical |
Years Made | 2021-2022 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 68.0 HP | 50.7 kW |
Lifting Capacity (35% Tipping) | ||
Lifting Capacity (50% Tipping) | 2300 lbs | 1043.3 kg |
Operating Weight | 6974 lbs | 3163.4 kg |
Tipping Load | 4600 lbs | 2086.5 kg |
Lift Breakout Force | ||
Tilt Breakout Force | ||
Max. Travel Speed | 7.4 mph | 11.9 km |
Optional High Speed | 11.0 mph | 17.7 km |
Cycle Time
Raise Lift Arms | 3.2 sec. |
Lower Lift Arms | 2.4 sec. |
Bucket Rollback | 1.9 sec. |
Bucket Dump | 2.4 sec. |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 17.6 GPM | 66.5 LPM |
Relief Pressure | 3500 psi | 241.3 Bar |
Optional Flow | 26.9 GPM | 101.8 LPM |
Hydraulic Capacity | 9.5 gal | 36.0 L |
How much does a Bobcat S64 weight?
Bobcat S64 is 7,000 pounds in weight.
How much can a Bobcat S64 lift?
The Bobcat S64 has a 2,300-pound lifting capacity.
How many HP is a Bobcat S64?
Bobcat S64 has 68 HP.
What engine is in a Bobcat S64?
The Bobcat S64 has an engine made by Bobcat called the 2.4L V2.
What is the Bobcat S64’s oil capacity?
The oil capacity of the Bobcat S64 is 2.4 gallons.
Engine Specs
Manufacturer | Bobcat |
Model | 2.4L V2 |
Type | Diesel |
Emissions | Tier 4 |
Cylinders | 4 |
Rated Speed | 2600 RPM |
Torque Power | 1800 RPM |
Combustion | Direct injection |
Compression Ratio | 17.0:1 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 68.0 HP | 50.7 kW |
Displacement | 146.5 cu.in. | 2401 cc |
Bore | ||
Stroke | ||
Peak Torque | 185.9 ft-lb | 250.8 N∙m |
Coolant Capacity | 3.0 gal | 11.3 L |
Engine Oil Capacity | 2.4 gal | 9.0 L |
Fuel Tank Capacity | 28.3 gal | 107.1 L |
Dimensions
US | Metric | |
---|---|---|
Height | 80.5 in. | 204.5 cm |
Bucket Hinge Pin | 120.0 in. | 304.8 cm |
Width | 64.6 in. | 167.6 cm |
Length | 135.0 in. | 342.9 cm |
Dump Height | ||
Dump Reach | 34.2 in. | 86.9 cm |
Ground Clearance |
Dump Angle | |
Rollback Angle | |
Departure Angle |
Tire Size
Front | 10-16.5 |
Rear | 10-16.5 |
Bobcat S64 Review
Reliability
Specifications
Price
The Bobcat s64 skid steer loader has both fixed joystick controls and standard controls. It has C52 comfort features like a comfortable, adjustable vinyl suspension seat and an enclosed cab with HVAC. The P68 performance package, which includes Dual-Direction Bucket Positioning, 7-pin attachment control, and Standard Flow and Power Bob-Tach, is another option.
