Bobcat T630 Roller Suspension

Bobcat t650 roller suspension
TypeCompact track loader
Lift DesignVertical
Years Made2009-2022
The specifications for the Bobcat 630 roller suspension are listed in the tables below. To see the classic t630 Bobcat specs, click the icon below.

Bobcat T630 Roller Suspension Specs

Detailed information on the Bobcat T630 Roller Suspension specs may be found in the tables below. We advise keeping the Bobcat T630 Roller Suspension's model year in mind when perusing its technical specs. The Bobcat T630 Roller Suspension's dimensions, weight, horsepower, and lifting capacity were take advantage of from the owner's manuals. Before you buy an Bobcat T630 Roller Suspension, it's important to double-check the specifications with the vendor. The ABobcat T630 Roller Suspension review that you've been waiting for will be available on our site shortly.

Operating Specifications

Horsepower74.3 HP55.4 kW
Lifting Capacity (35% Tipping)1980 lbs898.1 kg
Lifting Capacity (50% Tipping)2900 lbs1315.4 kg
Operating Weight9650 lbs4377.2 kg
Tipping Load5657 lbs2566.0 kg
Lift Breakout Force6200 lbs2812.3 kg
Tilt Breakout Force6000 lbs2721.6 kg
Push Force6200 lbs2812.3 kg
Max. Travel Speed6.6 mph10.6 km
Optional High Speed10.7 mph17.2 km
Ground Pressure5.8 psi40.0 kPa

Cycle Time

Raise Lift Arms3.4 sec.
Lower Lift Arms3.0 sec.
Bucket Rollback1.7 sec.
Bucket Dump2.3 sec.

Hydraulic System

Pump Flow23.0 GPM87.1 LPM
Relief Pressure3550 psi244.8 Bar
Optional Flow30.5 GPM115.5 LPM
Hydraulic Capacity11.0 gal41.6 L

Engine Specs

Rated Speed2400 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio20.0
Firing Order1-3-4-2
Gross Power74.3 HP55.4 kW
Net Power70.3 HP55.4 kW
Displacement203.3 cu in.3331 cc
Bore3.7 in.9.4 cm
Stroke4.7 in.12.0 cm
Peak Torque195.0 ft-lb264.4 N∙m
Coolant Capacity3.1 gal11.7 L
Engine Oil Capacity3.0 gal11.4 L
Fuel Tank Capacity27.3 gal103.3 L


Height81.3 in.206.5 cm
Bucket Hinge Pin121.0 in.307.3 cm
Width72.9 in.185.1 cm
Length136.8 in.347.4 cm
Dump Height93.2 in.236.7 cm
Dump Reach24.1 in.61.2 cm
Ground Clearance9.2 in.23.3 cm
Dump Angle42°
Rollback Angle31°
Departure Angle31°


Track Width12.6 in.32.0 cm
Track Length108.4 in.275.3 cm
Ground Contact Length59.0 in.149.9 cm
