Bobcat T66

Bobcat t66 specs
ManufacturerBobcat
ModelT66
TypeCompact track loader
Lift DesignVertical
Years Made2020
The following specs belong to the Bobcat T66 standard undercarriage. By clicking the buttons below, you can examine the torsion suspension model specifications.
Bobcat T66 Torsion Suspension

Operating Specifications

USMetric
Horsepower74.0 HP55.2 kW
Lifting Capacity (35% Tipping)2450 lbs1111.3 kg
Lifting Capacity (50% Tipping)3500 lbs1587.6 kg
Operating Weight8927 lbs4049.2 kg
Tipping Load7000 lbs3175.1 kg
Lift Breakout Force4474 lbs2029.4 kg
Tilt Breakout Force5085 lbs2306.5 kg
Push Force7587 lbs3441.4 kg
Max. Travel Speed10.2 mph16.4 km
Ground Pressure5.9 psi40.7 kPa

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow17.6 GPM66.5 LPM
Relief Pressure3500 psi241.3 Bar
Optional Flow26.9 GPM101.8 LPM
Hydraulic Capacity13.6 gal51.1 L

Engine Specs

ManufacturerBobcat
Model
TypeDiesel
Cylinders4
EmissionsTier 4 – Stage V
Rated Speed2600 RPM
Torque Power1800 RPM
CombustionDirect injection
Compression Ratio
Firing Order
USMetric
Gross Power74.0 HP55.2 kW
Net Power70.0 HP52.2 kW
Displacement146.5 cu in.2401 cc
Bore3.5 in.9.0 cm
Stroke3.7 in.9.4 cm
Peak Torque283.9 ft-lb384.9 N∙m
Coolant Capacity3.0 gal11.3 L
Engine Oil Capacity
Fuel Tank Capacity28.3 gal107.1 L

Dimensions

USMetric
Height80.5 in.204.5 cm
Bucket Hinge Pin120.0 in.304.8 cm
Width68.0 in.172.7 cm
Length134.9 in.342.7 cm
Dump Height94.3 in.239.6 cm
Dump Reach34.2 in.86.7 cm
Ground Clearance7.5 in.18.9 cm
Dump Angle37°
Rollback Angle31°
Departure Angle25°

Undercarriage

USMetric
Track Width12.6 in.32.0 cm
Track Length
Ground Contact Length54.3 in.137.9 cm
