Bobcat t750 specs

Bobcat T750

Last Check:
Bobcat t750 specs
ManufacturerBobcat
ModelT750
TypeCompact track loader
Lift DesignVertical
Years Made2011-2015
The Bobcat t750 standard version has the following characteristics. To see the features of the optional roller suspension version, click the button at the bottom.
Bobcat T750 Roller Suspension

Operating Specifications

USMetric
Horsepower85.0 HP63.4 kW
Lifting Capacity (35% Tipping)3325 lbs1508.2 kg
Lifting Capacity (50% Tipping)4750 lbs2154.6 kg
Operating Weight10327 lbs4684.2 kg
Tipping Load9500 lbs4309.1 kg
Lift Breakout Force7000 lbs3175.1 kg
Tilt Breakout Force6500 lbs2948.4 kg
Max. Travel Speed6.6 mph10.6 km
Optional High Speed10.7 mph17.2 km
Ground Pressure4.2 psi29.0 kPa

Cycle Time

Raise Lift Arms4.8 sec.
Lower Lift Arms3.4 sec.
Bucket Rollback2.1 sec.
Bucket Dump2.3 sec.

Hydraulic System

USMetric
Pump Flow23.0 GPM87.1 LPM
Relief Pressure3550 psi244.8 Bar
Optional Flow36.5 GPM138.2 LPM
Hydraulic Capacity9.5 gal36.0 L

Engine Specs

ManufacturerBobcat
Model3.4L
TypeDiesel
EmissionsTier 4
Cylinders4
Rated Speed2400 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio17.0:1
Firing Order1-3-4-2
USMetric
Gross Power86.2 HP64.3 kW
Net Power82.2 HP63.1 kW
Displacement208 cu. in.3408 cc
Bore3.9 in.9.8 cm
Stroke4.5 in.11.3 cm
Peak Torque243.1 ft-lb329.6 N∙m
Coolant Capacity3.6 gal13.6 L
Engine Oil Capacity3.3 gal12.5 L
Fuel Tank Capacity44.1 gal166.9 L

Dimensions

USMetric
Height81.3 in.206.5 cm
Bucket Hinge Pin132.0 in.335.3 cm
Width78.0 in.198.1 cm
Length141.6 in.359.7 cm
Dump Height104.3 in.264.9 cm
Dump Reach33.6 in.85.3 cm
Ground Clearance7.8 in.19.8 cm
Dump Angle42°
Rollback Angle32°
Departure Angle29°

Undercarriage

USMetric
Track Width17.7 in.45.0 cm
Track Length114.3 in.290.3 cm
Ground Contact Length63.7 in.153.2 cm
