Manufacturer | Case |
Model | 40XT |
Type | Skid steer loader |
Lift Design | Radial |
Years Made | 2001-2005 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 60.0 HP | 44.7 kW |
Lifting Capacity (35% Tipping) | 1060 lbs | 480.8 kg |
Lifting Capacity (50% Tipping) | 1500 lbs | 680.4 kg |
Operating Weight | 5700 lbs | 2585.5 kg |
Tipping Load | 3000 lbs | 1360.8 kg |
Lift Breakout Force | 3800 lbs | 1723.7 kg |
Tilt Breakout Force | 4000 lbs | 1814.4 kg |
Max. Travel Speed | 6.8 mph | 11.0 km |
Cycle Time
Raise Lift Arms | 3.6 sec. |
Lower Lift Arms | 2.1 sec. |
Bucket Rollback | 1.8 sec. |
Bucket Dump | 1.9 sec. |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 19.1 GPM | 72.2 LPM |
Relief Pressure | 3000 psi | 206.8 Bar |
Optional Flow | N/A | |
Hydraulic Capacity | 13.3 gal | 50.2 L |
Engine Specs
Manufacturer | Case |
Model | 4-390 |
Type | Diesel |
Cylinders | 4 |
Emissions | |
Rated Speed | 2000 RPM |
Torque Power | 1200 RPM |
Combustion | Direct injection |
Compression Ratio | 17.0.1 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 60.0 HP | 44.7 kW |
Net Power | 56.0 HP | 41.8 kW |
Displacement | 239 cu in. | 3916.5 cc |
Bore | 4.0 in. | 10.2 cm |
Stroke | 4.7 in. | 12.0 cm |
Peak Torque | 177 ft-lb | 240 N∙m |
Coolant Capacity | 4.5 gal | 17.0 L |
Engine Oil Capacity | 2.7 gal | 10.4 L |
Fuel Tank Capacity | 22.0 gal | 83.3 L |
Dimensions
US | Metric | |
---|---|---|
Height | 75.5 in. | 191.8 cm |
Bucket Hinge Pin | 114.6 in. | 291.1 cm |
Width | 49 in. | 124.5 cm |
Length | 129 in. | 327.7 cm |
Dump Height | 85.9 in. | 218.2 cm |
Dump Reach | 28.1 in. | 71.4 cm |
Ground Clearance | 8.0 in. | 20.3 cm |
Dump Angle | 40° |
Rollback Angle | 32° |
Departure Angle | 27° |
Tire Size
Front | 10 x 16.5 |
Rear | 10 x 16.5 |
