Cat 247b

Cat 247b specs
ManufacturerCaterpillar
Model247b
TypeCompact track loader
Lift DesignVertical
Years Made2004-2007

Operating Specifications

USMetric
Horsepower62.0 HP46.2 kW
Lifting Capacity (35% Tipping)1367 lbs620.1 kg
Lifting Capacity (50% Tipping)1950 lbs884.5 kg
Operating Weight6668 lbs3024.6 kg
Tipping Load3907 lbs1772.2 kg
Lift Breakout Force3127 lbs1418.4 kg
Tilt Breakout Force3734 lbs1693.7 kg
Max. Travel Speed7.6 mph12.2 km
Ground Pressure3.8 psi26.2 kPa

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow15.6 GPM59.1 LPM
Relief Pressure3335 psi230.0 Bar
High FlowN/A
Hydraulic Capacity14.5 gal55.0 L

Engine Specs

ManufacturerCat
Model3024CT
TypeDiesel
Cylinders4
EmissionsTier 2
Rated Speed3000 RPM
Torque Power2600 RPM
CombustionIndirect injection
Compression Ratio23.3:1
Firing Order1-3-4-2
USMetric
Gross Power60.2 HP44.9 kW
Net Power57.0 HP42.5 kW
Displacement134 cu in.2196 cc
Bore3.3 in.8.4 cm
Stroke3.9 in.10.0 cm
Peak Torque
Coolant Capacity2.6 gal10.0 L
Engine Oil Capacity2.1 gal8.0 L
Fuel Tank Capacity17.2 gal65.0 L

Dimensions

USMetric
Height78.0 in.198.1 cm
Bucket Hinge Pin112.0 in.248.5 cm
Width66.0 in.167.6 cm
Length129.0 in.327.7 cm
Dump Height84.0 in.213.4 cm
Dump Reach25.0 in.63.5 cm
Ground Clearance10.0 in.25.4 cm
Dump Angle40°
Rollback Angle
Departure Angle41°

Undercarriage

USMetric
Track Width15.0 in.38.1 cm
Track Length99.0 in.251.5 cm
Ground Contact Length59.0 in.149.9 cm
