Cat 267b

Last Check:
cat 267b
ManufacturerCaterpillar
Model267B
TypeCompact track loader
Lift DesignVertical
Years Made2004-2007

Operating Specifications

USMetric
Horsepower73.0 HP54.4 kW
Lifting Capacity (35% Tipping)2030 lbs920.8 kg
Lifting Capacity (50% Tipping)2900 lbs1315.4 kg
Operating Weight9370 lbs4250.2 kg
Tipping Load5800 lbs2630.8 kg
Lift Breakout Force4656 lbs2111.9 kg
Tilt Breakout Force5484 lbs2487.5 kg
Max. Travel Speed7.0 mph11.2 km
Ground Pressure3.1 psi21.7 kPa

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow21.9 GPM83.0 LPM
Relief Pressure3335 psi229.9 Bar
High FlowN/A
Hydraulic Capacity13.7 gal52.0 L

Engine Specs

ManufacturerCat
Model3044C DIT
TypeDiesel
Cylinders4
EmissionsStage 2
Rated Speed2600 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio16:2.1
Firing Order1-3-4-2
USMetric
Gross Power73.0 HP54.4 kW
Net Power71.0 HP52.9 kW
Displacement201 cu in.3394 cc
Bore3.7 in.9.4 cm
Stroke4.7 in.12.0 cm
Peak Torque254 ft-lb344.4 N∙m
Coolant Capacity2.6 gal10.0 L
Engine Oil Capacity2.6 gal10.0 L
Fuel Tank Capacity25.1 gal95.0 L

Dimensions

USMetric
Height81.7 in.207.4 cm
Bucket Hinge Pin121.7 in.309.1 cm
Width74.7 in.189.8 cm
Length145.0 in.368.4 cm
Dump Height92.5 in.234.9 cm
Dump Reach26.6 in.67.6 cm
Ground Clearance13.9 in.35.3 cm
Dump Angle40°
Rollback Angle
Departure Angle62°

Undercarriage

USMetric
Track Width18.0 in.45.7 cm
Track Length115.1 in.292.3 cm
Ground Contact Length80.5 in.204.5 cm
