Gehl Rt105

Gehl rt105 specs
ManufacturerGehl
ModelRt105
TypeCompact track loader
Lift DesignRadial
Years Made2020-2022

Gehl Rt105 Specs

Details about the Gehl Rt105 specs are listed below. When looking at the technical specs of the Gehl Rt105, we suggest keeping the model year in mind. The manufacturer's manuals were used to list the Gehl Rt105's weight, horsepower, lifting capacity, and other specifications. Before you buy the Gehl Rt105, check with the seller about the technical specs. We will soon add a review of the Gehl Rt105 to help you with your purchase.

Operating Specifications

USMetric
Horsepower34.7 HP25.5 kW
Lifting Capacity (35% Tipping)1050 lbs476.3 kg
Lifting Capacity (50% Tipping)1500 lbs680.4 kg
Operating Weight4720 lbs2141.0 kg
Tipping Load3000 lbs1360.8 kg
Lift Breakout Force3042 lbs1379.8 kg
Tilt Breakout Force2975 lbs1349.4 kg
Drawbar Pull4400 lbs1995.8 kg
Max. Travel Speed6.3 mph10.1 km
Ground Pressure4.8 psi33.1 kPa

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow14.5 GPM54.9 LPM
Relief Pressure
High Flow – XPSN/A
Hydraulic Capacity8.0 gal30.3 L
How much does a Gehl RT105 weight?

Gehl RT105 is 4,720 pounds in weight.

What is the horsepower of a Gehl RT105?

The Gehl RT105 has 35 horsepower.

What is the lifting capacity of the Gehl RT105?

The Gehl RT105 has the lifting capacity of 1,500 lbs.

What is the engine in the Gehl RT105?

The Yanmar 3TNV88C engine powers the Gehl RT105.

How wide is an Gehl 3640E?

Gehl RT105 is 51 inches wide.

Engine Specs

ManufacturerYanmar
Model3TNV88C-KMSV
TypeDiesel
Cylinders4
EmissionsTier 4 / Stage 5
Rated Speed2800 RPM
Torque Power1820 RPM
CombustionDirect injection
Compression Ratio
Firing Order1-3-4-2
USMetric
Gross Power34.7 HP25.9 kW
Net Power31.8 HP23.7 kW
Displacement100 cu in.1642 cc
Bore3.7 in.9.4 cm
Stroke4.4 in.11.2 cm
Peak Torque80.7 ft-lb109.4 N∙m
Coolant Capacity1.7 gal6.6 L
Engine Oil Capacity1.6 gal5.9 L
Fuel Tank Capacity10.3 gal39.0 L

Dimensions

USMetric
Height71.5 in.181.6 cm
Bucket Hinge Pin109.0 in.276.9 cm
Width50.8 in.129.0 cm
Length117.5 in.298.5 cm
Dump Height84.0 in.213.4 cm
Dump Reach26.5 in.67.3 cm
Ground Clearance7.5 in.19.1 cm
Dump Angle38°
Rollback Angle32°
Departure Angle25°

Undercarriage

USMetric
Track Width9.8 in.24.9 cm
Track Length88.9 in.225.8 cm
Ground Contact Length40.9 in.103.9 cm

Gehl Rt105 Review

Reliability
Specifications
Price

The Gehl Rt105 is a small track loader with an excellent power-to-maneuver ratio. Attachments for the Gehl rt 105 track include buckets, forks, grapples, rippers, pallet forks, and augers. The Gehl Rt105 compact track loader is ideal for small businesses or homeowners.

User Rating: Be the first one !
