Home » Gehl » Gehl Rt175

Gehl Rt175

Gehl rt175 specs
ManufacturerGehl
ModelRt175
TypeCompact track loader
Lift DesignRadial
Years Made2013
The Gehl RT175 specs shown below are for serial numbers 10720 and earlier.

Gehl Rt175 Specs

The following tables include a listing of the Gehl Rt175 specs. When review the table of Gehl Rt175, it is important to take into consideration the production year. The user's manuals provided by the manufacturer were consulted in order to ascertain the appropriate values for the Gehl Rt175's weight, lifting capability, and horsepower, among other technical specifications. Before you make a purchase, it is must that you verify the product's technical specs with the vendor. In order to assist you in making an informed buying decision, we will provide an Gehl Rt175 review as soon as feasible.

Operating Specifications

USMetric
Horsepower69.9 HP52.1 kW
Lifting Capacity (35% Tipping)1750 lbs794 kg
Lifting Capacity (50% Tipping)2500 lbs1134 kg
Operating Weight8600 lbs3900 kg
Tipping Load5000 lbs2268 kg
Lift Breakout Force4840 lbs2195 kg
Tilt Breakout Force5200 lbs2360 kg
Max. Travel Speed5.1 mph8.2 km
Optional High Speed7.5 mph12.1 km
Ground Pressure6.2 psi42.7 kPa

Cycle Time

Raise Lift Arms4.5 sec.
Lower Lift Arms3.0 sec.
Bucket Rollback2.1 sec.
Bucket Dump2.7 sec.

Hydraulic System

USMetric
Pump Flow18.5 GPM70.0 LPM
Relief Pressure3000 psi206.8 Bar
Optional High Flow34.0 GPM128.7 LPM
Hydraulic Capacity18.5 gal70.0 L
How much does a Gehl RT175 weigh?

The Gehl RT175 weighs 8,600 pounds.

How much can the Gehl RT175 lift?

The Gehl RT175 has the lifting capacity of 2,500 lbs.

How many horsepower is a Gehl RT175?

The Gehl RT175 has a 70 horsepower rating.

What engine is in a Gehl RT175?

The Gehl RT175 has an engine made by Yanmar called the 4TNV98.

What is the fuel capacity of the Gehl RT175?

The fuel capacity of the Gehl RT175 is 24 gallons.

Engine Specs

ManufacturerYanmar
Model4TNV98-ZNMS
TypeDiesel
Cylinders4
EmissionsTier 3
Rated Speed2500 RPM
Torque Power1600 RPM
CombustionDirect injection
Compression Ratio18.5:1
Firing Order1-3-4-2
USMetric
Gross Power69.9 HP52.1 kW
Net Power68.4 HP51.0 kW
Displacement203 cu in.3318 cc
Bore3.8 in.9.8 cm
Stroke4.3 in.11.0 cm
Peak Torque179 ft-lb243 N∙m
Coolant Capacity3.5 gal13.2 L
Engine Oil Capacity2.7gal10.4 L
Fuel Tank Capacity24.4 gal92.4 L

Dimensions

USMetric
Height82.8 in.210.3 cm
Bucket Hinge Pin127.5 in.323.9 cm
Width64.4 in.163.6 cm
Length152.3 in.386.8 cm
Dump Height98.0 in.248.9 cm
Dump Reach34.5 in.87.6 cm
Ground Clearance13.3 in.34.3 cm
Dump Angle40°
Rollback Angle33°
Departure Angle30°

Undercarriage

USMetric
Track Width12.6 in.32.0 cm
Track Length110.8 in.281.4 cm
Ground Contact Length54.8 in.139.2 cm

Gehl Rt175 Review

Reliability
Specifications
Price

The Gehl RT175 is a compact loader with a 175-horsepower, turbocharged diesel engine. It has a wide range of features and capabilities that make it an attractive option for many different types of construction and excavation work.
