| Manufacturer | JCB |
| Model | 1110t |
| Type | Compact track loader |
| Lift Design | Vertical |
| Years Made | 2001-2013 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 92.0 HP | 68.6 kW |
| Lifting Capacity (35% Tipping) | 2250 lbs | 1020.6 kg |
| Lifting Capacity (50% Tipping) | 3220 lbs | 1460.6 kg |
| Operating Weight | 10200 lbs | 4626.6 kg |
| Tipping Load | 8200 lbs | 3719.5 kg |
| Lift Breakout Force | 4450 lbs | 2018.5 kg |
| Tilt Breakout Force | 4400 lbs | 1995.8 kg |
| Max. Travel Speed | 6.2 mph | 10.0 km |
| Ground Pressure | 4.8 psi | 33.1 kPa |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 20.0 GPM | 75.7 LPM |
| Relief Pressure | 2682 psi | 184.9 Bar |
| Optional High Flow | 32.0 GPM | 121.1 LPM |
| Hydraulic Capacity | 9.2 gal | 107.0 L |
Engine Specs
| Manufacturer | |
| Model | |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 (2001-2008) Tier 4 (2008-2013) |
| Rated Speed | 2200 RPM |
| Torque Power | 1200 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 92.0 HP | 68.6 kW |
| Net Power | 82.0 HP | 61.5 kW |
| Displacement | 177 cu in. | 2901 cc |
| Bore | 3.5 in. | 8.8 cm |
| Stroke | 4.0 in. | 10.2 cm |
| Peak Torque | 272 ft-lb | 368.8 N∙m |
| Coolant Capacity | 3.9 gal | 14.8 L |
| Engine Oil Capacity | 2.8 gal | 10.6 L |
| Fuel Tank Capacity | 28.2 gal | 106.7 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 79.9 in. | 202.9 cm |
| Bucket Hinge Pin | 123.2 in. | 313.0 cm |
| Width | 65.0 in. | 165.2 cm |
| Length | 137.8 in. | 350.0 cm |
| Dump Height | 96.0 in. | 243.9 cm |
| Dump Reach | 38.0 in. | 96.5 cm |
| Ground Clearance | 11.0 in. | 27.9 cm |
| Dump Angle | 40° |
| Rollback Angle | 30° |
| Departure Angle | 28° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 17.7 in. | 45.0 cm |
| Track Length | ||
| Ground Contact Length | 59.1 in. | 151.9 cm |
