| Manufacturer | JCB |
| Model | 210 |
| Type | Skid steer loader |
| Lift Design | Radial |
| Years Made | 2017-2022 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 55.2 kW |
| Lifting Capacity (35% Tipping) | 1500 lbs | 680.4 kg |
| Lifting Capacity (50% Tipping) | 2100 lbs | 952.5 kg |
| Operating Weight | 6900 lbs | 4127.7 kg |
| Tipping Load | 4230 lbs | 1918.7 kg |
| Lift Breakout Force | 4130 lbs | 1873.3 kg |
| Tilt Breakout Force | 3960 lbs | 1796.2 kg |
| Max. Travel Speed | 7.5 mph | 12.0 km |
| Optional High Speed | 11.5 mph | 18.5 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.5 GPM | 70.0 LPM |
| Relief Pressure | 3335 psi | 229.9 Bar |
| Optional High Flow | 30.4 GPM | 115.1 LPM |
| Hydraulic Capacity | 11.5 gal | 43.5 L |
Engine Specs
| Manufacturer | Kohler |
| Model | KDI2504TCR/26A |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2800 RPM |
| Torque Power | 1200 RPM |
| Combustion | Direct injection |
| Compression Ratio | |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 46.0 HP | 34.3 kW |
| Net Power | ||
| Displacement | 151 cu in. | 2482 cc |
| Bore | 3.5 in. | 8.8 cm |
| Stroke | 4.0 in. | 10.2 cm |
| Peak Torque | 221.2 ft-lb | 300.2 N∙m |
| Coolant Capacity | 2.6 gal | 10.0 L |
| Engine Oil Capacity | 2.0 gal | 7.4 L |
| Fuel Tank Capacity | 24.3 gal | 92.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 78.0 in. | 198.1 cm |
| Bucket Hinge Pin | 118.2 in. | 300.2 cm |
| Width | 59.9 in. | 152.1 cm |
| Length | 137.4 in. | 349.0 cm |
| Dump Height | 89.1 in. | 226.4 cm |
| Dump Reach | 22.0 in. | 56.0 cm |
| Ground Clearance | 8.3 in. | 21.0 cm |
| Dump Angle | 42° |
| Rollback Angle | 30° |
| Departure Angle | 25° |
Tire Size
| Front | 10×16.5 |
| Rear | 10×16.5 |
