Manufacturer | John Deere |
Model | 270 |
Type | Skid steer loader |
Lift Design | Vertical |
Years Made | 2002-2006 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 82.0 HP | 61.1 kW |
Lifting Capacity (35% Tipping) | 2000 lbs | 907.2 kg |
Lifting Capacity (50% Tipping) | 2800 lbs | 1270.1 kg |
Operating Weight | 8500 lbs | 3855.5 kg |
Tipping Load | 5600 lbs | 2540.1 kg |
Lift Breakout Force | 7430 lbs | 3370.2 kg |
Tilt Breakout Force | ||
Max. Travel Speed | 7.0 mph | 11.3 km |
Optional High Speed | 12.0 mph | 19.3 km |
Cycle Time
Raise Lift Arms | |
Lower Lift Arms | |
Bucket Rollback | |
Bucket Dump |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 21.3 GPM | 66.6 LPM |
Relief Pressure | 3100 psi | 213.7 Bar |
Optional Flow | 34.9 GPM | 113.9 LPM |
Hydraulic Capacity | 9.0 gal | 34.1 L |
The John Deere 270 skid steer weighs 8,500 pounds.
The John Deere 270 has a 2,800-pound lifting capacity.
The JD 270 has 82 horsepower.
The John Deere 270 skid steer is powered by a John Deere 4045D engine.
The John Deere 270’s oil capacity is 2 gallons.
Engine Specs
Manufacturer | John Deere |
Model | 4045D |
Type | Diesel |
Cylinders | 4 |
Emissions | Tier I |
Rated Speed | 2400 RPM |
Torque Power | 1600 RPM |
Combustion | Direct injection |
Compression Ratio | 17.6:1 |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 82.0 HP | 61.1 kW |
Net Power | 77.0 HP | 57.4 kW |
Displacement | 276 cu in. | 4523 cc |
Bore | 4.2 in. | 10.6 cm |
Stroke | 5.0 in. | 12.7 cm |
Peak Torque | ||
Coolant Capacity | 2.8 gal | 10.6 L |
Engine Oil Capacity | 2.0 gal | 7.4 L |
Fuel Tank Capacity | 20.0 gal | 75.7 L |
Dimensions
US | Metric | |
---|---|---|
Height | 82.9 in. | 210.5 cm |
Bucket Hinge Pin | 127.0 in. | 322.6 cm |
Width | 76.2 in. | 193.5 cm |
Length | 138.0 in. | 350.4 cm |
Dump Height | 102.0 in. | 259.1 cm |
Dump Reach | 32.0 in. | 81.3 cm |
Ground Clearance | 11.0 in. | 28.0 cm |
Dump Angle | 45° |
Rollback Angle | 35° |
Departure Angle | 27° |
Tire Size
Front | 14×17.5 |
Rear | 14×17.5 |
The John Deere 270 skid steer loader is a great machine for those who want something simple and reliable, but also powerful enough to handle all of the farm tasks. The JD 270 loader has specs that set it apart from other machines on the market today.John Deere 270 Review
