| Manufacturer | John Deere |
| Model | 280 Series 2 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2002-2006 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 90.0 HP | 67.1 kW |
| Lifting Capacity (35% Tipping) | 2420 lbs | 1097.7 kg |
| Lifting Capacity (50% Tipping) | 3200 lbs | 1451.5 kg |
| Operating Weight | 9200 lbs | 4173.4 kg |
| Tipping Load | 7000 lbs | 3175.1 kg |
| Lift Breakout Force | 11600 lbs | 5261.7 kg |
| Tilt Breakout Force | ||
| Max. Travel Speed | 7.0 mph | 11.3 km |
| Optional High Speed | 12.0 mph | 19.3 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 28.0 GPM | 106.0 LPM |
| Relief Pressure | 3100 psi | 213.7 Bar |
| Optional Flow | 48.5 GPM | 183.6 LPM |
| Hydraulic Capacity | 9.0 gal | 34.1 L |
Engine Specs
| Manufacturer | John Deere |
| Model | 4045T |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier I |
| Rated Speed | 2400 RPM |
| Torque Power | 1600 RPM |
| Combustion | Direct injection |
| Compression Ratio | 17.6:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 90.0 HP | 67.1 kW |
| Net Power | 85.0 HP | 63.4 kW |
| Displacement | 276 cu in. | 4523 cc |
| Bore | 4.2 in. | 10.6 cm |
| Stroke | 5.0 in. | 12.7 cm |
| Peak Torque | ||
| Coolant Capacity | 5.5 gal | 20.8 L |
| Engine Oil Capacity | 3.5 gal | 13.3 L |
| Fuel Tank Capacity | 24.0 gal | 90.8 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 82.9 in. | 210.5 cm |
| Bucket Hinge Pin | 127.0 in. | 322.6 cm |
| Width | 77.2 in. | 196.1 cm |
| Length | 138.0 in. | 350.4 cm |
| Dump Height | 102.0 in. | 259.1 cm |
| Dump Reach | 32.0 in. | 81.3 cm |
| Ground Clearance | 9.5 in. | 24.1 cm |
| Dump Angle | 45° |
| Rollback Angle | 35° |
| Departure Angle | 27° |
Tire Size
| Front | 14×17.5 |
| Rear | 14×17.5 |
