John Deere 318G

john deere 318g specs
ManufacturerJohn Deere
Model318G
TypeSkid steer loader
Lift DesignVertical
Years Made2017-2022

John Deere 318G Specs

This page that follow provide details about the John Deere 318G specs. When reviewing the specifications for the John Deere 318G, it is essential to consider the years made. The John Deere 318Gs weight, lifting capacity, and horsepower, as well as other technical specifications, were determined by reading the manufacturer-supplied user manuals. Before making a purchase, it is important that you confirm the product's technical specifications with the seller. We will publish an John Deere 318G review as soon as possible in order to help you make an informed purchasing decision.

Operating Specifications

USMetric
Horsepower65.0 HP48.5 kW
Lifting Capacity (35% Tipping)1350 lbs612.3 kg
Lifting Capacity (50% Tipping)1945 lbs882.3 kg
Operating Weight6540 lbs2966.5 kg
Tipping Load3890 lbs1764.5 kg
Lift Breakout Force5250 lbs2381.4 kg
Tilt Breakout Force6000 lbs2751.6 kg
Max. Travel Speed6.9 mph10.8 km
Optional High Speed10.1 mph16.3 km

Cycle Time

Raise Lift Arms
Lower Lift Arms
Bucket Rollback
Bucket Dump

Hydraulic System

USMetric
Pump Flow17.0 GPM64.4 LPM
Relief Pressure3450 psi238 Bar
Optional High FlowN/AN/A
Hydraulic Capacity18.0 gal68.1 L
How much can a John Deere 318G lift?

John Deere 318G lifts 1950 lbs.

How much does a John Deere 318G weight?

The weight of the John Deere 318G is 6540 pounds.

How much horsepower is a 318G John Deere skid steer?

The John Deere 318G has 65 horsepower.

What is the engine in the John Deere 318G?

The engine that powers the John Deere 318G is manufactured by Yanmar and is as model number 4TNV86CHT.

How much fuel does a John Deere 318G take?

The fuel capacity of the John Deere 318G is 2.1 gallons.

Engine Specs

ManufacturerYanmar
Model4TNV86CHT
TypeDiesel
Cylinders4
EmissionsTier 4
Rated Speed2600 RPM
Torque Power1690 RPM
CombustionDirect injection
Compression Ratio19:1
Firing Order1-3-4-2
USMetric
Gross Power65.0 HP48.5 kW
Net Power61.0 HP45.5 kW
Displacement128 cu in.2091 cc
Bore3.4 in.8.6 cm
Stroke3.5 in.9.0 cm
Peak Torque207 ft-lb153 N∙m
Coolant Capacity3.2 gal12.0 L
Engine Oil Capacity
Fuel Tank Capacity19.0 gal71.9 L

Dimensions

USMetric
Height77.2 in.196.0 cm
Bucket Hinge Pin120.0 in.305.0 cm
Width62.9 in.160.0 cm
Length127.6 in.324.0 cm
Dump Height94.3 in.240.0 cm
Dump Reach34.0 in.86.0 cm
Ground Clearance7.0 in.18.0 cm
Dump Angle42°
Rollback Angle30°
Departure Angle22°

Tire Size

Front10×16.5
Rear10×16.5
