| Manufacturer | John Deere |
| Model | 326e |
| Type | Skid steer |
| Lift Design | Vertical |
| Years Made | 2014-2018 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 74.0 HP | 54.8 kW |
| Lifting Capacity (35% Tipping) | ||
| Lifting Capacity (50% Tipping) | 2690 lbs | 1221 kg |
| Operating Weight | 8200 lbs | 3723 kg |
| Tipping Load | 5380 lbs | 2443 kg |
| Lift Breakout Force | 5000 lbs | 2270 kg |
| Tilt Breakout Force | 7750 lbs | 3519 kg |
| Max. Travel Speed | 6.9 mph | 11.1 km |
| Optional High Speed | 11.1 mph | 17.9 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 21.0 GPM | 80.0 LPM |
| Relief Pressure | 3450 psi | 337.8 Bar |
| Optional Flow | 29.0 GPM | 110.0 LPM |
| Hydraulic Capacity |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV98CT |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 – Stage 5 |
| Rated Speed | 2500 RPM |
| Torque Power | 1800 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.1:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 74.0 HP | 54.8 kW |
| Net Power | 70.0 HP | 52.2 kW |
| Displacement | 203 cu in. | 3319 cc |
| Bore | 3.9 in. | 9.8 cm |
| Stroke | 4.3 in. | 11.0 cm |
| Peak Torque | 207 ft-lb | 280 N∙m |
| Coolant Capacity | ||
| Engine Oil Capacity | ||
| Fuel Tank Capacity | 24.0 gal | 92.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 83.3 in. | 211.6 cm |
| Bucket Hinge Pin | 125.4 in. | 318.5 cm |
| Width | 72.6 in. | 184.4 cm |
| Length | 144.0 in. | 365.8 cm |
| Dump Height | 99.9 in. | 253.7 cm |
| Dump Reach | 33.0 in. | 83.8 cm |
| Ground Clearance | 9.7 in. | 24.6 cm |
| Dump Angle | 45° |
| Rollback Angle | 35° |
| Departure Angle | 26° |
