Manufacturer | Kubota |
Model | SCL1000 |
Type | Mini track loader |
Lift Design | Vertical |
Years Made | 2020-2025 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 24.8 HP | 18.5 kW |
Lifting Capacity (35% Tipping) | 1000 lbs | 453 kg |
Lifting Capacity (50% Tipping) | 1300 lbs | 590 kg |
Operating Weight | 3035 lbs | 1376 kg |
Tipping Load | 2857 lbs | 1296 kg |
Max. Travel Speed | 4.9 mph | 7.9 km |
Ground Pressure | 4.0 psi | 28.0 kPa |
Cycle Time
Raise Lift Arms | |
Lower Lift Arms | |
Bucket Rollback | |
Bucket Dump |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 15.0 GPM | 56.8 LPM |
Relief Pressure | 2800 psi | 193 Bar |
Optional Flow | N/A | |
Hydraulic Capacity | 6.0 gal | 22.7 L |
Engine Specs
Manufacturer | Kubota |
Model | D902-T |
Type | Diesel |
Cylinders | 3 |
Emissions | Tier 4F |
Rated Speed | 2800 RPM |
Torque Power | 2200 RPM |
Combustion | Indirect injection |
Compression Ratio | |
Firing Order | 1-2-3 |
US | Metric | |
---|---|---|
Gross Power | 24.8 HP | 18.5 kW |
Net Power | 23.8 HP | 17.8 kW |
Displacement | 54.8 cu in. | 893 cc |
Bore | 2.8 in. | 7.1 cm |
Stroke | 2.9 in. | 7.4 cm |
Peak Torque | 52.3 ft-lb | 72.2 N∙m |
Coolant Capacity | ||
Engine Oil Capacity | ||
Fuel Tank Capacity | 7.75 gal | 29.3 L |
Dimensions
US | Metric | |
---|---|---|
Height | 55.8 in. | 141.7 cm |
Bucket Hinge Pin | 84.7 in. | 215.1 cm |
Width | 35.8 in. | 90.9 cm |
Length | 107.7 in. | 273.5 cm |
Dump Height | 60.8 in. | 154.4 cm |
Dump Reach | 26.0 in. | 66.0 cm |
Ground Clearance | 7.4 in. | 18.8 cm |
Dump Angle | 45° |
Rollback Angle | 23° |
Departure Angle | 25° |
Undercarriage
US | Metric | |
---|---|---|
Track Width | 9.8 in. | 24.9 cm |
Track Length | 84.9 in. | 215.6 cm |
Ground Contact Length | 40.5 in. | 102.3 cm |
