| Manufacturer | Kubota |
| Model | Ssv65 |
| Type | Skid steer loader |
| Lift Design | Vertical |
| Years Made | 2015-2022 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 64.0 HP | 47.7 kW |
| Lifting Capacity (35% Tipping) | 1350 lbs | 612.3 kg |
| Lifting Capacity (50% Tipping) | 1950 lbs | 884.5 kg |
| Operating Weight | 7050 lbs | 3197.8 kg |
| Tipping Load | 3900 lbs | 1769.0 kg |
| Lift Breakout Force | 3850 lbs | 1764.3 kg |
| Tilt Breakout Force | 4850 lbs | 2199.9 kg |
| Max. Travel Speed | 11.1 mph | 17.9 km |
Cycle Time
| Raise Lift Arms | |
| Lower Lift Arms | |
| Bucket Rollback | |
| Bucket Dump |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 18.0 GPM | 68.1 LPM |
| Relief Pressure | 3271 psi | 225.5 Bar |
| Optional Flow | 28.0 GPM | 106.0 LPM |
| Hydraulic Capacity | 4.2 gal | 16.0 L |
Engine Specs
| Manufacturer | Kubota |
| Model | V2607-CR-TE4 |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 4 |
| Rated Speed | 2700 RPM |
| Torque Power | 1500 RPM |
| Combustion | Direct injection |
| Compression Ratio | 19.0 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 64.0 HP | 47.7 kW |
| Net Power | 61.3 HP | 45.7 kW |
| Displacement | 160 cu in. | 2615 cc |
| Bore | 3.5 in. | 8.7 cm |
| Stroke | 4.4 in. | 11.0 cm |
| Peak Torque | 166 ft-lb | 225.1 N∙m |
| Coolant Capacity | 2.7 gal | 10.3 L |
| Engine Oil Capacity | 1.8 gal | 6.8 L |
| Fuel Tank Capacity | 25.4 gal | 96.0 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 79.9 in. | 202.9 cm |
| Bucket Hinge Pin | 121.5 in. | 308.5 cm |
| Width | 66.5 in. | 168.9 cm |
| Length | 135.4 in. | 343.9 cm |
| Dump Height | 92.4 in. | 234.7 cm |
| Dump Reach | 32.7 in. | 83.1 cm |
| Ground Clearance | 7.6 in. | 19.3 cm |
| Dump Angle | 41° |
| Rollback Angle | 24° |
| Departure Angle | 41° |
Tire Size
| Front | 10-16.5-8PR |
| Rear | 10-16.5-8PR |
