Manufacturer | New Holland |
Model | C190 |
Type | Compact track loader |
Lift Design | Vertical |
Years Made | 2006-2011 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 90.0 HP | 67.1 kW |
Lifting Capacity (35% Tipping) | 4143 lbs | 1879 kg |
Lifting Capacity (50% Tipping) | 2900 lbs | 1315 kg |
Operating Weight | 9820 lbs | 4128 kg |
Tipping Load | 8286 lbs | 3758 kg |
Lift Breakout Force | 7670 lbs | 3479 kg |
Tilt Breakout Force | 6229 lbs | 2825 kg |
Max. Travel Speed | 5.1 mph | 8.2 km |
Optional High Speed | 8.0 mph | 12.9 km |
Ground Pressure | 4.8 psi | 33.1 kPa |
Cycle Time
Raise Lift Arms | 3.3 sec. |
Lower Lift Arms | 3.1 sec. |
Bucket Rollback | 1.6 sec. |
Bucket Dump | 1.8 sec. |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 21.9 GPM | 82.9 LPM |
Relief Pressure | 3050 psi | 172.4 Bar |
Optional Flow | 37.3 GPM | 141.2 LPM |
Hydraulic Capacity | 15.0 gal | 56.8 L |
Engine Specs
Manufacturer | FPT |
Model | F4G E9454 |
Type | Diesel |
Cylinders | 4 |
Emissions | Tier 3 |
Rated Speed | 2450 RPM |
Torque Power | 1100 RPM |
Combustion | Direct |
Compression Ratio | |
Firing Order | 1-3-4-2 |
US | Metric | |
---|---|---|
Gross Power | 90.0 HP | 67.1 kW |
Net Power | 83.0 HP | 61.9 kW |
Displacement | 274 cu in. | 4490 cc |
Bore | 4.1 in. | 10.4 cm |
Stroke | 5.2 in. | 13.2 cm |
Peak Torque | 288 ft-lb | 390 N∙m |
Coolant Capacity | 4.5 gal | 17.4 L |
Engine Oil Capacity | 3.0 gal | 11.6 L |
Fuel Tank Capacity | 26.5 gal | 100.3 L |
Dimensions
US | Metric | |
---|---|---|
Height | 80.1 in. | 203.6 cm |
Bucket Hinge Pin | 127.4 in. | 323.7 cm |
Width | 82.6 in. | 209.7 cm |
Length | 148.2 in. | 376.4 cm |
Dump Height | 102.6 in. | 260.6 cm |
Dump Reach | 34.4 in. | 87.4 cm |
Ground Clearance | 10.4 in. | 26.4 cm |
Dump Angle | 45° |
Rollback Angle | 39° |
Departure Angle | 28° |
Undercarriage
US | Metric | |
---|---|---|
Track Width | 15.7 in. | 39.9 cm |
Track Length | ||
Ground Contact Length | 64.7 in. | 164.3 cm |
