| Manufacturer | Takeuchi |
| Model | TL120 |
| Type | Compact track loader |
| Lift Design | Radial |
| Years Made | 2007-2009 |
Operating Specifications
| US | Metric | |
|---|---|---|
| Horsepower | 52.0 HP | 38.8 kW |
| Lifting Capacity (35% Tipping) | 1250 lbs | 567.0 kg |
| Lifting Capacity (50% Tipping) | 1800 lbs | 816.5 kg |
| Operating Weight | 5950 lbs | 2698.9 kg |
| Tipping Load | 3550 lbs | 1610.3 kg |
| Lift Breakout Force | 5050 lbs | 2290.6 kg |
| Tilt Breakout Force | 4800 lbs | 2177.2 kg |
| Max. Travel Speed | 4.0 mph | 5.8 km |
| Ground Pressure | 4.6 psi | 31.7 kPa |
Cycle Time
| Raise Lift Arms | 3.6 sec. |
| Lower Lift Arms | 2.4 sec. |
| Bucket Rollback | 1.7 sec. |
| Bucket Dump | 2.6 sec. |
Hydraulic System
| US | Metric | |
|---|---|---|
| Pump Flow | 15.1 GPM | 57.2 LPM |
| Relief Pressure | 3000 psi | 206.8 Bar |
| Optional Flow | N/A | |
| Hydraulic Capacity | 7.7 gal | 29.1 L |
Engine Specs
| Manufacturer | Yanmar |
| Model | 4TNV84T-XTBL |
| Type | Diesel |
| Cylinders | 4 |
| Emissions | Tier 3 |
| Rated Speed | 2800 RPM |
| Torque Power | 1680 RPM |
| Combustion | Direct injection |
| Compression Ratio | 18.9:1 |
| Firing Order | 1-3-4-2 |
| US | Metric | |
|---|---|---|
| Gross Power | 52.0 HP | 38.8 kW |
| Net Power | 50.5 HP | 37.7 kW |
| Displacement | 119.3 cu in. | 1955 cc |
| Bore | 3.3 in. | 8.4 cm |
| Stroke | 3.5 in. | 9.0 cm |
| Peak Torque | 123 ft-lb | 167 N∙m |
| Coolant Capacity | 2.9 gal | 11.0 L |
| Engine Oil Capacity | 2.0 gal | 7.6 L |
| Fuel Tank Capacity | 15.3 gal | 57.9 L |
Dimensions
| US | Metric | |
|---|---|---|
| Height | 77.6 in. | 197.1 cm |
| Bucket Hinge Pin | 114.4 in. | 290.6 cm |
| Width | 57.9 in. | 147.1 cm |
| Length | 126.8 in. | 322.1 cm |
| Dump Height | 89.6 in. | 227.6 cm |
| Dump Reach | 23.1 in. | 58.7 cm |
| Ground Clearance | 9.8 in. | 24.9 cm |
| Dump Angle | 39° |
| Rollback Angle | 30° |
| Departure Angle | 29° |
Undercarriage
| US | Metric | |
|---|---|---|
| Track Width | 11.8 in. | 30.0 cm |
| Track Length | 103.8 in. | 263.7 cm |
| Ground Contact Length | 48.9 in. | 124.2 cm |
