Manufacturer | Takeuchi |
Model | TS80V2 |
Type | Skid steer loader |
Lift Design | Vertical |
Years Made | 2016-2025 |
Operating Specifications
US | Metric | |
---|---|---|
Horsepower | 74.0 HP | 55.2 kW |
Lifting Capacity (35% Tipping) | 2250 lbs | 1021 kg |
Lifting Capacity (50% Tipping) | 3005 lbs | 1363 kg |
Operating Weight | 9115 lbs | 4134 kg |
Tipping Load | 6010 lbs | 2726 kg |
Lift Breakout Force | 6200 lbs | 2812 kg |
Tilt Breakout Force | 5920 lbs | 2685 kg |
Max. Travel Speed | 8.2 mph | 13.1 km |
Optional High Speed | 11.0 mph | 17.7 km |
Cycle Time
Raise Lift Arms | |
Lower Lift Arms | |
Bucket Rollback | |
Bucket Dump |
Hydraulic System
US | Metric | |
---|---|---|
Pump Flow | 26.0 GPM | 98.4 LPM |
Relief Pressure | 3335 psi | 229.9 Bar |
Optional Flow | 31.0 GPM | 117.3 LPM |
Hydraulic Capacity | 10 gal | 37.9 L |
Engine Specs
Manufacturer | Deutz |
Model | TD2.9L4 |
Type | Diesel |
Cylinders | 4 |
Rated Speed | 2600 RPM |
Torque Power | 1800 RPM |
Combustion | Indirect injection |
Emissions | Tier 4 |
Compression Ratio | |
Firing Order |
US | Metric | |
---|---|---|
Gross Power | 74 HP | 55.2 kW |
Displacement | 177 cu in. | 2900 cc |
Bore | 3.6 in. | 9.2 cm |
Stroke | 4.3 in. | 11.0 cm |
Peak Torque | 192 ft-lb | 260.3 N∙m |
Coolant Capacity | 5.0 gal | 19.0 L |
Engine Oil Capacity | 2.2 gal | 8.5 L |
Fuel Tank Capacity | 28.0 gal | 106.0 L |
Dimensions
US | Metric | |
---|---|---|
Height | 84.0 in. | 213.4 cm |
Bucket Hinge Pin | 130.0 in. | 330.2 cm |
Width | 72.0 in. | 182.9 cm |
Length | 146.0 in. | 370.8 cm |
Dump Height | 103.0 in. | 261.6 cm |
Dump Reach | 25.0 in. | 63.5 cm |
Ground Clearance | 10.5 in. | 26.7 cm |
Dump Angle | 39° |
Rollback Angle | 30° |
Departure Angle | 24° |
Tire Size
Front | 12×16.5 |
Rear | 12×16.5 |
